Reference Architectures
Configurations we ship, numbers we publish
Most module work ships under NDA, so this page plays by a stricter rule than a logo wall: every deployment is told as a customer type, a configuration and a number. If a pattern below looks like your rack, your nacelle or your crane, the 48-hour quote is the fastest way to find out how close it is.
How we publish projects
No logos. Architecture, configuration, numbers.
Pilot fleets below started at 2–10 sample units and grew into frame orders of 1,000+ pcs a year. The stories are the same in every industry: a load profile, a matched module, and a metric worth measuring twice. Ask us live and the same six patterns come with dates, durations and references you can call.
Deployment patterns
Six architectures, told straight
AI · Hyperscaler rack integrator
48V pilot fleet in power-shelf BBU bays
RackBridge 48V modules — 48.6 V / 166 F class, active balancing, CAN telemetry — qualified into sealed BBU bays with batch data archived per serial.
±5% batch-to-batch C/ESR consistency
Wind · OEM pitch retrofit
Pitch cabinets swapped from lead-acid
Cold-site fleets where lead-acid drops out below −20 °C: low-temperature pitch-backup modules keep feathering authority with the grid lost, rated to −40 °C.
−40 °C cranking · 500k+ cycle class
Rail · Tram energy-recovery pilot
Braking-energy pack, onboard duty cycle
A supercapacitor pack sized against hundreds of brake events per day, absorbing regeneration spikes and releasing them into acceleration — a duty cycle batteries refuse.
Million-cycle-class endurance target
Port · Crane hybridization
Diesel RTG crane hybrid retrofit
High C-rate modules recycle potential energy on every hoist and lower, shaving lift peaks so the genset idles through moves instead of chasing them.
Peak kW shaved on every lift cycle
Telecom · 48V bridge tier
Ride-through ahead of genset start
48V supercap strings carrying seconds-to-minutes bridge duty until generators pick up — sized for a 15-year design-life class in unmanned sites.
500k+ cycle class · no battery strings
Utility · Metering RTC backup
12/24V modules behind metering clocks
Low-voltage modules with µA-class sleep draw hold real-time clocks and comms through outages, across a −40 … +70 °C cabinet envelope.
<20 µA standby draw
How programs run
The unglamorous half of trust
A test report rides with every serial number and every cell is traceable to its bin — the evidence exists before the invoice does.
100% loggedStandard parts start at 2–10 sample pcs, custom modules at 50–100 pcs, and annual frame agreements step in from 1,000 pcs.
2 → 1,000+ pcsEvery RFQ comes back with a cell count, a capacitance number and a lead time — the same numbers these six patterns were built on.
48 h RFQ response
Your architecture next
Bring a load profile. Leave with a configuration.
All six patterns above started as a messy spreadsheet and a quote that came back within 48 hours. Yours can start the same way.
